Features of the Model 2000 serie
Model 2200 is a semi-open canopies, suitable for a single row of bicycles and/or scooters. By extending in the width direction, an open canopy is created, Model 2400, suitable for a double row of bicycles. Further extension to Model 2600 creates a canopy with a covered walkway.
Extension possible
Can be extended to a canopy with a double row of bicycles and possibly a covered walkway.
Linkable
They can be linked in width and length. This creates a range of possibilities for any specific application and any location.
Specifications
- Size 501 x 287 cm, suitable for 12 bicycles, centre to centre 37,5 cm.
- Column spacing at centre 480 x 183 cm.
- Clear height 205 cm.
- Columns made of steel tube 70 x 70 x 3 mm, frames and purlins made of IPE 80 and IPE 100.
- Gutters made of pressed sheet steel, thickness 3 mm. Rainwater drainage integrated in the steel structure.
- Hot-dip galvanised, NEN-EN-ISO 1461.
- Corrugated polyester canopy in the natural colour, fixed with corrugated aluminium strips to prevent storm damage.
- Walls of vertical open lathing, made of hardwood.
- Buoys of rebated timber, made of hardwood.
- Hardwood parts treated with water-based transparent varnish.
- Foundation: concrete legs, height 37 cm.
Options
- Two or more canopies can be joined together lengthwise and/or widthwise.
- Deviations from standard dimensions possible.
- Canopy of galvanised or coated corrugated steel sheet.
- Canopy Model 2200 and 2400 of steel sheet piling.
- Walls made of various types of wood with FSC® quality mark, hard glass, Trespa, steel or aluminium trapezoidal sheets, steel grids or perforated sheets.
- Cuffs of galvanised or coated steel sheet or of Trespa.
- Continuous walls, without buoys.
- Additional walls and/or doors. These can be used to (partially) lock up the roof.
- Wooden parts finished with an opaque lacquer.
- Powder-coated steel parts in any desired RAL colour.
Flexible possibilities
Model 2000 serie offers all the freedom you need to create a canopy in various ways. There is a great variety of designs, materials and colours. Model 2000 serie can also be extended in length and width as desired. This creates a range of possibilities for each specific application and location.
