Model 800

Features of the Model 800 bike shelter

Model 800 is a practical and multifunctional roofing, suitable for storing bicycles and scooters. Protect your bikes from the elements with this beautiful bike garage.

Multifunctional

Multifunctional canopy.

Options for walls/doors

Use walls and/or doors as you wish.

Many possibilities

Can be designed as required, from a (semi-)open bicycle shelter to a lockable storage room.

Specifications

Size 501 x 576 cm, suitable for 24 bicycles, centre to centre 37,5 cm.
Column spacing at centre 480 x 550 cm.
Clear height 205 cm.
Columns made of steel tube 70 x 70 x 3 mm, IPE 80 and IPE 100 rafters and purlins.
Gutters of formed sheet steel, thickness 3 mm. Rainwater drainage integrated in the steel structure.
Hot-dip galvanised, NEN-EN-ISO 1461.
Corrugated polyester roof in the natural colour, fixed with corrugated aluminium strips to prevent storm damage.
Walls of vertical open lathing, made of hardwood.
Hardwood parts treated with water-based transparent varnish.
Foundation: concrete legs, height 37 cm.

Options

Two or more canopies can be joined together lengthwise and/or widthwise.
Deviations from standard dimensions possible.
Roof available in galvanised or coated corrugated steel sheets.
Walls made of various types of wood with FSC® quality mark, hard glass, Trespa, steel or aluminium sheet piling, steel grids or perforated sheets.
Cuffs of galvanised or coated steel sheet or of Trespa.
Continuous walls, without shackles.
Single or double revolving door, sliding door or steel tilting door.
Wooden parts finished with opaque lacquer.
Powder-coated steel parts in any desired RAL colour.
